Originally designed for the automotive industry, EE03 can be used as stand alone device or as plug in module for data loggers, handheld and other devices. Due to its construction EE03 is ideal for monitoring surface humidity and temperature and especially for detecting near-condensation (dew point) conditions.
The E+E proprietary sensor coating allows for EE03 to be employed even in aggressive and corrosive environment. Customised versions are possible.
- Measuring range
- 0...100% RH-40...85 °C (-40...185 °F)
- Accuracy
- ±3% RH±0.3 °C (±0.54 °F)
- Output
- digital E2 (2-wires)
- Supply
- 2.5-5.5V DC
FAQ
The maximum cable length depends on the product, clock speed, and pull-up resistor, and can be up to 10m. For detail please see E2 interface for humidity probes/modules.
Only one E+E device can be connected to the E2 interface of a controller.
Downloads EE03
